1. 7” Color LCD Touch Screen, it can display the information of patients by extracting the data from HIS system. There are daytime mode and night mode for option.
2. It can remind patients to do physical check and to take pill on time.
3. It can call the nursing.
4. Light control (need to buy the light controller additionally).
5. Reinforcing, broadcasting, television and radio functions.
6. It has a handle calling device.
7. When the substation is calling, the ward door station and master station of nurse station will voice broadcast.
Model |
E5BC-G32-70 |
Power Source |
DC12V |
Power Consumption |
≤5W |
Network Protocol |
TCP/UDP/RTP |
Network Chip Rate |
10/100Mbps |
Audio Sampling |
22.050kHz-44.1Khz, 16bit |
Transmit Rate |
16k~192k bps |
Display |
7” Color LCD Touch Screen |
Interface |
Audio output, 2 short-circuit input, 2 short-circuit output, SD card holder, RJ45 |
Dimensions |
240*115*35mm |
