1. Plastic shell, desktop design, can be
fixed on table or wall.
2. Double call buttons, can call different
goals (set in server), realize dull-duplex talkback.
3. Built-in speaker and microphone,
hands-free call and broadcasting receiving.
4. Digital recording, upload to server
automatically.
5. With audio output interface, can connect
to external speaker.
6. Short-circuit output for connect
electronic lock or alarm light, etc.
7. Remote software update, configuration
monitoring.
8. Works everywhere as long as Ethernet is
available.

|
Model |
TB-8225 |
|
Power Source |
DC12V |
|
Power Consumption |
≤5W |
|
Network Protocol |
TCP/UDP/RTP |
|
Network Chip Rate |
10/100Mbps |
|
Audio Sampling |
22.050kHz-44.1kHz, 16bit |
|
Transmit Rate |
16k~192k bps |
|
Audio Coding |
SILK, PCM |
|
Camera |
None |
|
Interface |
Audio output, 4 short-circuit input, 2 short-circuit output, SD card holder, RJ45 |
|
Dimensions |
140*166*70mm |
